Main Characters

Support both ITU-T G.984.x GPON and IEEE802.3ah GEPON standard,

Compatible with Huawei, ZTE, Fiberhome, Nokia, HOMEFIBER GPON OLTs.

IEEE802.11ac 867Mbps + IEEE802.11n 300Mbps Wi-Fi Router for Excellent Wi-Fi experiences

EasyMesh controller, support a 1500 square meters of WiFi coverage with multiple Mesh agents

1* SC/UPC GPON / GEPON WAN port, 2.5G download and 1.25G upload

2 * Gigabit Ethernet LAN ports, wire-speed data transmission

AES 128-bit encrypted and key switching, enhancing transmission security

Layer 2 Switching, support 802.1Q VLAN, 802.1P QoS, Bandwidth Control, Spanning Tree, etc

Layer 3 Home Gateway/CPE features with Hardware NAT, support Multiple WAN, Route/Bridge mode, etc

Port Binding, different LAN ports can be assigned with different WAN services

Max 1:128 Fiber ration, max transmission distance can reach 20km

Max 1:64 Fiber ratio for GEPON, max transmission distance can reach 20km

Support FEC (Forward Error Correction), ensures high reliable and precise data transmission

Support Dynamic Bandwidth Allocation (DBA), Smarter bandwidth assignment and usage.

Support OMCI and TR069 Management, manage subscribers remotely.

Supports IPv4 and IPv6, highly applicable in both IP type based networks.

Support Mesh IEEE802.11 k/v/r, IEEE802.11s protocols

Support 253 on LAN cable ( DHCP Limit) but only 64 in each wifi ( 64 for 2.4G + 64 for 5G).

Technical Parameters

GPON Parameters

ITU-T G.984.x GPON, built-in with a -30dBm Optical BOSA , SC/UPC or SC/APC connector optional 1310nm upstream & 1490nm downstream Support G.984.1 General Characteristics Support G.984.2 Physical Media Dependent (PMD) layer Specification Support G.984.3 Transmission convergence layer Specification GPON transceiver transmitting power: 0.5-5dbm, Optical receiving sensitivity: -30dBm Transmission wavelength: Upstream: 1310nm / Downstream: 1490nm Support 1:128 Fiber Ratio at 20km transmission distance. Fiber Transmission cable: G.652 Single mode optical fiber cable Configurable AES decryption on downstream payload. Configurable FEC on both upstream and downstream payloads. Multi-Application Processor queues for dedicated connections for in-band. Enhanced GPON debug and diagnostic functions. Support up to 40 Transmission Container (T-Cons) Support 256 bidirectional GEM port IDs Support NSR/SR Dynamic Bandwidth Allocation (DBA) Support Forward Error Correction (FEC) Maximum 2.5Gbps Downlink/1.25 Gbps Uplink Support Dying Gasp
